Hikvision DS-KD6002-VM Video Intercom Metal Door Station

System Parameters Processor: High-Performance Embedded SOC Processor Operation System: Embedded Linux Operation System Video Parameters Camera: CMOS Low Illumination 1.3 MP HD Colorful Camera Video Compression Standard: H.264 Resolution: 1280 x 720 Video frame rate: PAL: 25 fps, NTSC: 30 fps Display Parameters Display Screen: 3.5-Inch Colorful TFT LCD Display Resolution: 480 × 320 Operation Method: Physical Keypad Operation interface: LCD Display, Easy Menu Audio Parameters Audio Output: Built-in Loudspeaker Audio Input: Built-in Omnidirectional Microphone Audio Compression Standard: G.711 U Audio Compression Rate: 64 Kbps Audio Quality: Noise Suppression and Echo Cancellation Network Parameters Ethernet: 10/100/1000 Mbps Self-Adaptive Ethernet Network Protocol: TCP/IP, RTSP Access Control Parameters Internal Card Reader: Built-in IC Card Reader External Card Reader: Wiegand 26, Wiegand 34, or RS-485 IC Reader Door Magnetic Detection: Detects Door Magnetic Status Light Supplement Light Supplement Mode: Visible Light Supplement Alarm Parameters Alarm Input: Door Magnetic Alarm, Tampering Alarm Device Interfaces Network Interface: 1 RJ-45 10/100/1000 Mbps Self-Adaptive Ethernet Interface RS-485: 1 RS-485 Half-Duplex Port I/O Input: 4 I/O Output: 4 Wiegand: 1 Wiegand Port for Accessing Wiegand IC Card Reader USB : 1 USB 2.0, Supporting U-Disk General Material: Aluminum Alloy Power Supply: 12 VDC Power Consumption: ≤15 W Certification: FCC, IC, CE, C-TICK, ROHS, REACH, WEEE Working Temperature: -40° C to 70° C (-40° F to 158° F) Working Humidity: 10% to 90% IP Protection Level: IP65
